Ausavina Stone Saw Mods2
FOB Price:
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Limestone, Onyx, Artificial Stone
After-Sale
Warranty:12 Months
Machinery Function Features
- The powerful Ausavina Stone Saw MODS2 is ideal for construction sites and workshops. On one side, the saw has a roller conveyor which makes for easy loading, while on the other side, the adjustable stops make exact parallel cuts. Incorporated in this machine are wheels and rollers for easy transportation.
- The MODS2 features an electric direct drive fully submersible water pump. Accessories include 2 side benches with rollers and 2 support arms with stops.
- The MODS2 features an electric direct drive fully submersible water pump. Accessories include 2 side benches with rollers and 2 support arms with stops.
Technical Data
Parameters |
Unit |
MODS2-1P-1 |
MODS2-1P-2 |
MODS2-3P-1 |
MODS2-3P-2 |
MODS2-3P-3 |
Machine height (H) |
mm |
1644 |
1644 |
1644 |
1644 |
1644 |
Main motor rotation speed |
r/min |
2800 |
2800 |
2800 |
2800 |
2800 |
Cutting depth at 90° |
mm |
50 |
60 |
50 |
60 |
80 |
Machine length (L) |
mm |
2110 |
2110 |
2110 |
2110 |
2110 |
Standard voltage |
V |
220 |
220 |
380 |
380 |
380 |
Diamond blade diameter |
mm |
254 |
300 |
254 |
300 |
350 |
Approximate weight |
Kg |
260 |
260 |
260 |
260 |
260 |
Cutting depth at 45° |
mm |
25 |
30 |
25 |
30 |
40 |
Water pump power |
V/w |
220 / 50 |
220 / 50 |
220 / 50 |
220 / 50 |
220 / 50 |
Standard frequency |
Hz |
50 |
50 |
50 |
50 |
50 |
Max. cutting length |
mm |
1650 |
1650 |
1650 |
1650 |
1650 |
Machine width (W) |
mm |
2108 |
2108 |
2108 |
2108 |
2108 |
Main motor power |
kw |
2.2 |
2.2 |
3.7 |
3.7 |
3.7 |
