Quarrying Wire Saw Machine For Marble

$17000-25000

Type: Quarry MachinesQuarry Wire Saw Machine
Usage: Granite, Marble
After-Sale
Lead Time: Within 25-30 days after receive deposit
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting
Contact supplier
XIAMEN EASTERN PEGASUS CO., LTD.
Quarrying Wire Saw Machine For Marble

ChinaChina level idicon

XIAMEN EASTERN PEGASUS CO., LTD.

Eatablished :Feb 26,2006

Main Product:

Quarry Machine;| Stone Cutting Machine| Stone Polishing Machine| Stone Crushing Machine| Other Machine| Stone Tools|

View Company profile
Machinery Function Features
1.Being controlled by two sets of inverters and applying constant tension control principle,the moving speed of the machine can be adjusted automatically acoording to the changes of the cutting force to make sure the diamond wire saw be in the best cutting condition allthe time.
2.The machine is without phase request.it doesn't need to change or distinguish the power phase.The machine has the following protection functions.wire broken protectlon,over loading protection,open-phase protection,terminal limit,and so on.
3.The lateral moving and the rotation angle of the cutting head are controlled and driven by electric motor.There is photoelectric proximity switch installed on the cuting head fol position imitation protection.This funtion enables the machine to work normally under harsh circumstance with moisture and dust.
4.The real-time parameters are displayed on the control platform,such as the set current of the main motor,the curront and the rotation speed of the main motor,etc.it makes the operation and adjustment of the machine more convenient.
5.The machine can be operated manually and automatically.The manual and automatic functions can be shifted from each other.Under the automatic function,the machine can be unattended operated,and one worker is able to operate multiple machines.
6.Using Permanent Magnet Synchronous Motor, the wire saw machine is more energy-saving, larger torque, and higher efficient.
Technical Data
Parameters
Unit
TJZY-45G-6P
Wire Saw Speed
m/s
0-40
Length of rails
m
2m*3+1m
Feed Motors Power
kw
0.75
Dimension LxWxH
mm
2320*1460*1450
Total Weight
T
2.8
Cutting Distance
m
1700
Max. Wire Length
m
20-80
Main Motor Power
kw
45(60HP-6P)
Processed Stone Photos
Components
Consumables
After-Sale
OperationVideo
Trade Terms

Port: XIAMEN

Delivery Details: FOB,CFR,CIF,EXW,Express Delivery

Payment: T/T,L/C,MoneyGram,Western Union
