Cheaper bridge saw for marble /quartz/granite JCQ-600
FOB Price:$15000-16000
Type:
Stone Factory MachinesStone Slab Cutting MachinesInfrared Bridge Cutting Machine
Usage:
Granite, Marble, Quartzite
After-Sale
Lead Time:
25days
Warranty:12 Months
Install and Guarantee:Customer pay for installation
Maintenance:Online software upgrade
You may also like
Machinery Function Features
This machine use computer control , and with its worktable rotating 0°-360°, 85° flap. Precision manufacturing assembly, and have special side beam protector, touch operate system , let it has high precision, high stability, high efficiency , operate simple and so one. Specially fit to high value big size granite and marble slab processing .
Technical Data
Parameters |
Unit |
JCQ-600 |
Machine length |
mm |
6000 |
Main motor power |
kW |
15 |
Working table rotating angle |
° |
0-360 |
Working table dimensions(L×W) |
mm |
3200x2000 |
Max. working dimensions(L×W×H) |
mm |
3200x2000x200 |
Machine height |
mm |
3200 |
Machine width |
mm |
4800 |
Worktable Weight |
kg |
2000 |
Total power |
kW |
18.5 |
Blade diameter |
mm |
350-600 |
Approximate weight without table |
kg |
4000 |
Working table tilting angle |
° |
0-85 |
Max. thickness cutting capacity |
mm |
200 |
