WG Series Impact Roll Crusher
FOB Price:
Type:
Stone Quarry MachinesRock Crushers, Jaw Crushers
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
35 day
Warranty:12 Months
Install and Guarantee:Customer pay for installation
Maintenance:Remote troubleshooting, Field troubleshooting
Trade Terms
Port:
XIAMEN- China
Delivery Details: FOB,CFR,CIF,EXW,Express Delivery
Payment :
Supplier
5YR
Eatablished :Sep 10,2018
Main Product:
Stone Machine, Cnc Machine, Cutting Machine, Polishiing Machine, Cutting Disc, Polishing Pad|
Machinery Function Features
WG Series Impact Roll Crusher
Technical Data
Parameters |
Unit |
WG1310 |
WG1315 |
WG1318 |
WG1518 |
WG1521 |
Dimension |
mm |
9400*2800*4500 |
10300*3300*4700 |
15000*3800*4000 |
16000*4300*5000 |
17000*5700*5800 |
Power of conveyor |
kw |
30 |
55-110 |
100-200 |
90-200 |
150-264 |
Receiving Area |
mm |
4700 |
5600 |
9500 |
10000 |
10000 |
Product size |
mm |
0-150 |
0-250 |
0-250 |
0-250 |
0-250 |
Power of Crusher |
kw |
90-132 |
230-320 |
320-500 |
315-630 |
500-630 |
Conveyor Width |
mm |
1000 |
1435 |
1435 |
1425 |
1725 |
Crusher setting adjustment |
mm |
1*50 |
5*20 |
10*20 |
10*20 |
10*20 |
Feeding Width |
mm |
950 |
1400 |
1800 |
1750 |
2000 |
Max Crusher inlet opening |
mm |
1090*1390 |
1470*1390 |
1810*1760 |
1810*1610 |
2160*1680 |
Average feed size |
mm |
950*880*X |
1400*1800*X |
1750*1000*X |
1750*1100*X |
2000*1100*X |
Rotor Diameter |
mm |
1305 |
1305 |
1300 |
1500 |
1500 |
Rotor Width |
mm |
990 |
1450 |
1800 |
1800 |
2150 |
