Portable Vacuum Diamond Core Drill Set- Stone Hand Drill Machines
FOB Price:
Type:
Stone Hand Held MachinesStone Hand Drill Machines
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:6 Months
Install and Guarantee:Remote guidance installation
Maintenance:Remote troubleshooting
Machinery Function Features
Vacuum diamond core drill Set
With our new Weha diamond drilling set, you are perfectly equipped for smooth and rough surfaces.
Vacuum created by hand pump
Vacuum created by compressed air ejector (you only need a small compressor with about 120 liters per minute delivery)
With control device (manometer) over existing vacuum
rotatable drill column
Stepless height adjustment of the drilling unit on rack
Pre-load of the machine weight by special device on the drill stand
Drilling machine with integrated water flushing bush
Drill to CE standard with PRCD circuit breaker in the cable, integrated for maximum safety
manually switchable mechanical three-speed transmission
exchangeable suction plate
3 speeds (950/1800/3450 rpm)
Connection thread: R1 / 2 "female thread and 1 1/4" UNC male thread
Dimensions base plate with vacuum unit: 540 x 150 mm
Dimensions base plate standard: 500 x 150 mm
Set includes:
1 drill stand with vacuum hand pump and ejector
1 vacuum suction plate and device for connecting a wet vacuum cleaner (wet vacuum cleaner is not included)
1 diamond drill with 1500 watts and 3-speed gearbox in practical storage case
Adapters for other diameter of the drill available as an option
With our new Weha diamond drilling set, you are perfectly equipped for smooth and rough surfaces.
Vacuum created by hand pump
Vacuum created by compressed air ejector (you only need a small compressor with about 120 liters per minute delivery)
With control device (manometer) over existing vacuum
rotatable drill column
Stepless height adjustment of the drilling unit on rack
Pre-load of the machine weight by special device on the drill stand
Drilling machine with integrated water flushing bush
Drill to CE standard with PRCD circuit breaker in the cable, integrated for maximum safety
manually switchable mechanical three-speed transmission
exchangeable suction plate
3 speeds (950/1800/3450 rpm)
Connection thread: R1 / 2 "female thread and 1 1/4" UNC male thread
Dimensions base plate with vacuum unit: 540 x 150 mm
Dimensions base plate standard: 500 x 150 mm
Set includes:
1 drill stand with vacuum hand pump and ejector
1 vacuum suction plate and device for connecting a wet vacuum cleaner (wet vacuum cleaner is not included)
1 diamond drill with 1500 watts and 3-speed gearbox in practical storage case
Adapters for other diameter of the drill available as an option
Technical Data
Parameters |
Unit |
Vacuum Diamond Core Drill |
Overall width |
mm |
150 |
Collar |
mm |
60 |
Air requirement |
lt/min. |
120 |
Rated voltage |
V |
230 |
Rotating speed/Drilling speed |
r/min |
950/1800/3450 |
Overall length |
mm |
540 |
Output power |
w |
1500 |
