Manta 100 Radial Sawing Machine, Mitre Saw For Marble -Granite -Stone
FOB Price:
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:6 Months
Install and Guarantee:Remote guidance installation
Maintenance:Remote troubleshooting
Supplier
Eatablished :Jan 01,1960
Main Product:
Saw Blades , Stone Abrasives, Polishing Tools, Epoxy Resin, Stone Machinery|
Contact supplier
Machinery Function Features
Radial sawing machine for marble, granite and stone.
Robust, accurate, versatile and economical. Extremely accurate with head sliding bymeans of linear ball bearings on two chrome-plated and ground bars.
It is equipped with a submersed pump inside the base for disc cooling water regeneration. Vertical motion of the head by means of handwheel for stable and fast control.
Inclinable head for 45° cuts.
ACCESSORIES:
1 Stop
Transport handles
Set of wrenches
Robust, accurate, versatile and economical. Extremely accurate with head sliding bymeans of linear ball bearings on two chrome-plated and ground bars.
It is equipped with a submersed pump inside the base for disc cooling water regeneration. Vertical motion of the head by means of handwheel for stable and fast control.
Inclinable head for 45° cuts.
ACCESSORIES:
1 Stop
Transport handles
Set of wrenches
Technical Data
Parameters |
Unit |
Manta 65 |
Manta 85 |
Manta 100 |
Manta 120 |
Manta 150 |
disc thickness |
mm |
110 |
110 |
110 |
110 |
110 |
Max stone thickness |
mm |
650 |
850 |
1000 |
1200 |
1500 |
Machine width (W) |
mm |
660 |
660 |
660 |
660 |
660 |
Main motor rotation speed |
r/min |
2800 |
2800 |
2800 |
2800 |
2800 |
Blade bore size |
mm |
25,4 |
25,4 |
25,4 |
25,4 |
25,4 |
Approximate weight |
Kg |
90 |
105 |
120 |
160 |
180 |
Machine length (L) |
mm |
1100 |
1270 |
1400 |
1600 |
1970 |
Max. cutting length |
mm |
130 |
130 |
130 |
130 |
130 |
Diamond blade diameter |
mm |
350 |
350 |
350 |
350 |
350 |
Machine height (H) |
mm |
770 |
770 |
770 |
770 |
770 |
