edge cutting machine small cutter for granite/marble
FOB Price:$4300-4800
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Quartzite
After-Sale
Lead Time:
20days
Warranty:12 Months
Install and Guarantee:Customer pay for installation
Maintenance:Online software upgrade
Supplier
Eatablished :Dec 24,2010
Main Product:
Bridge Cutting Machine , Profiling Stone Line Machine , Wire Saw Machine , Edge Cutting Machine|
Contact supplier
Machinery Function Features
JCQ-800 cutting machine
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
JCQ-800A cutting machine
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
JCQ-800A cutting machine
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
Technical Data
Parameters |
Unit |
JCQ-800/800A |
Approximate weight |
kg |
2000/1800 |
Standard voltage |
V |
380 |
Machine height (H) |
mm |
2000/2400 |
Main motor power |
kW |
7.5 |
Machine length (L) |
mm |
5400/4200 |
Angle of cutter |
° |
+-90° |
Machine width (W) |
mm |
2200/2000 |
Standard frequency |
Hz |
50 |
Diamond blade diameter |
mm |
350-500 |
Worktable dimensions |
mm |
3200*1000*150/2600*800*150 |
Max stone thickness |
mm |
150 |
Processed Stone Photos
Components
-
Schneider, Omron
