Som-maK 10 + 2 Heads Edge Polishing Chamfering Machine
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesEdge Profiling, Polishing Machine
Usage:
Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Remote troubleshooting, Field troubleshooting
You may also like
Machinery Function Features
Our Marble Granite Chamfering Machine provides Serial Standard production.
Easy to operate and maintain and Use
The feature of our machine is that it chamfering from the bottom.
The polished part of the marble is put on the band as Next.
Our Face Polishing Machine is fully automatic
Belt movement is electronically speed controlled.
Our machine is produced as 6 + 2 8 + 2 10 + 2 12 + 2 14 + 2 standard according to the Granite and Marble Type.
The engine part of our machine is completely free of water and protected from water with inner and outer protective enclosures.
Back of Abrasive Seals protecting head bearings are heat and abrasion resistant Felts.
All heads on the machine work independently from each other.
If desired, heads can be disabled according to the process.
The polishing heads come and go automatically with the entrance of the stone and automatically close and go back when the stone leaves the swishh.
There are 1 caliber, 5 bottom chamfer, 6 face chamfer, 1 deburring and 1 dropper saw on our 12 + 2 machine.
Our machine PROCESSES a maximum of 1500 mm with a minimum 70/80 mm lower support Jib Mechanism.
The Bandwidth of our machine is 450.
Our machine is Front Control Panel Controlled.
Protection Panels for Lubrication Channels Abrasive Replacement Fully Open and Close with Shock Absorber Support.
Herringbone diamonds can be integrated into our machine according to special requests.
Easy to operate and maintain and Use
The feature of our machine is that it chamfering from the bottom.
The polished part of the marble is put on the band as Next.
Our Face Polishing Machine is fully automatic
Belt movement is electronically speed controlled.
Our machine is produced as 6 + 2 8 + 2 10 + 2 12 + 2 14 + 2 standard according to the Granite and Marble Type.
The engine part of our machine is completely free of water and protected from water with inner and outer protective enclosures.
Back of Abrasive Seals protecting head bearings are heat and abrasion resistant Felts.
All heads on the machine work independently from each other.
If desired, heads can be disabled according to the process.
The polishing heads come and go automatically with the entrance of the stone and automatically close and go back when the stone leaves the swishh.
There are 1 caliber, 5 bottom chamfer, 6 face chamfer, 1 deburring and 1 dropper saw on our 12 + 2 machine.
Our machine PROCESSES a maximum of 1500 mm with a minimum 70/80 mm lower support Jib Mechanism.
The Bandwidth of our machine is 450.
Our machine is Front Control Panel Controlled.
Protection Panels for Lubrication Channels Abrasive Replacement Fully Open and Close with Shock Absorber Support.
Herringbone diamonds can be integrated into our machine according to special requests.
Technical Data
Parameters |
Unit |
10 + 2 Heads |
Machine overall width |
mm |
1700 |
Diameter of the drip board saw blade |
mm |
250 |
Max. processing thickness |
mm |
40 |
Calibrating/shaping/cutting spindle power |
kw |
2.2 |
Total power |
kw |
21 |
Machine overall height |
mm |
2100 |
Number of dressing/polishing spindles |
nr |
5 |
Dressing/polishing spindle power |
kw |
1.5 |
Grinding spindle power |
kw |
1.5 |
Number of Bevelling/chamfering spindles |
nr |
4 |
Min. Cooling water pressure |
bar |
1-3 |
Min. processing width |
mm |
70 |
Machine overall length |
mm |
7100 |
Top Press Motor Power |
kw |
0.75 |
Belt advancement power |
kw |
1.5 |
Min. processing thickness |
mm |
10 |
Water consumption |
L/min |
32 |
No. calibrating/shaping/cutting spindles |
nr |
1 |
Extending Table Width |
mm |
1400 |
Power of the disk for drip groove execution |
kw |
2.2 |
Belt advancement speed |
cm/min |
0 - 350 |
Bevelling /Chamfering spindle power |
kw |
1.5 |
