High Speed Single Blade Bridge Saw Middle Block Stone Cutting Machine
FOB Price:$25600-27600
Supplier
3YR
Eatablished :Jul 28,2015
Main Product:
Stone Block Cutting Machine, Bridge Saw Machine, Stone Polishing Machine, CNC Bridge Cutting Machine, Bridge Cutting Machine, Stone Profiling Machine|
Contact supplier
1.Super-heavy type working platform.The platform uses heavy large size profiles welding together,larger than the table in market,with more durable;
2.Taiwan famous hydraulic system.The hydraulic components from Taiwan first-line brand,react more quickly，works more stable;
3.Humanized human-computer interaction interface.User-friendly interface,with more simple operation,easy to use;
4.Inovance inverter, feeding more stable; imported or domestic premium brand electric components,with lower failure rate, help you to worry less and save more labor;
5.Domestic premium brand main motor with high efficiency and more energy saving,make the cutting more powerful,and saving electricity more;
6.Using permanent magnet synchronous motors(servo motors) for left and right walking and front and rear slicing. Compared with the current ordinary three-phase asynchronous motor,the speed increased 2 times for the retraction of front & rear splitting and the left & right walking,it makes the cutting much more efficiency;
7.High quanlity standard exported laser device, with longer service life and more lasting brightness;
Parameters |
Unit |
SQC1200-4D Pro |
SQC1400-4D Pro |
SQC1600-4D Pro |
Disch vertical stroke ( Z axis) |
mm |
850 |
850 |
850 |
Machine height |
mm |
4200 |
4400 |
4600 |
Average level of sound power |
dB |
80 |
80 |
80 |
Cooling water (1.5 bar pressure) |
m3/h |
5 |
5 |
5 |
Vertical disc diameter |
mm |
1200 |
1400 |
1600 |
Maximum block width |
mm |
1950 |
1950 |
1950 |
Vertical disc motor power |
kw |
30 |
30 |
30 |
Machine width |
mm |
4800 |
4800 |
4800 |
Maximum block length |
mm |
2950 |
2950 |
2950 |
Max. cutting depth |
mm |
450 |
550 |
650 |
Maximum block height |
mm |
450 |
550 |
650 |
Approximate Weight |
Kg |
7200 |
7400 |
7600 |
Machine length(front) |
mm |
6200 |
6200 |
6200 |
Installed power |
kw |
36 |
36 |
36 |
This machine adopts the PLC control system, floor type electric control cabinet, LCD touch screen (7 inches) using Chinese, English, Russian, Arabic, with the best human-computer interaction interface, the operation interface is a combination of touch screen and mechanical button to control the interface, input operating parameters through interface (including cutting size specification, moving speed) Etc., plus wireless remote control, the cutting process is automated and programmed.
SQC1200/1400/1600-4D Pro middle block bridge cutting machine.This series machine adopts microcomputer control system and human-machine interface, combined with ultra-high precision rotary encoder to locate and infrared device, uses inverter to control left-right feeding, adjusts the speed according to the stone material.
It uses hydraulic lifting system, combination of chrome-plated guide pin and wear guide bush, with small gap, wearable, beautiful structure, and guide sleeve with multi-layer seals, with waterproof, dust-proof, anti-spill, improving the service life, main motor uses brand energy-efficient motor, reduces the later using cost; worktable use super heavy large size profiles welding together, larger than the table in the market, with more durable.
Main parts adopt imported good-quality materials. Thus the whole machine is featured as high cutting efficiency, high cutting precision, high stability, easy–operating to suit specially cutting special-shaped stone, tombstone and curbstone.
-
-
-
-
-
-
