Quarry Hydro-Bags, Rock Splitter

( 52 )

Stone quarrying hydro bags are widely used in natural stone (marble, granite, basalt) quarrying to separate blocks from large masses in quarries. Hydro bags allow blocks of 1000 tons or more to be scrapped without the need to prepare slots to house jacks. The original thickness of the water bag is only 2 mm (0.08"), it can easily slip into a wire saw cut. Quarry Hydro bags, also known as Water Bags, are expanding hydraulic cushions composed of two high tensile steel plates. The water bags expand under the pressure of pumped water at 30-40 bar, allowing a maximum expansion of 25-30 cm (approximately 1') and a thrust of up to 1000 tons. The Hydro-bag is environmentally friendly as only running water (not oil as in hydraulic jacks) is the dilatation fluid. It is safe, even if the hydro-bag's cushion blows due to excessive inflation pressure there is no deflagration because water, not air, is the inflating media. The Hydro-bag does not require any maintenance, throw it away when it is no longer usable. The thrust that can be obtained for a pillow can be up to 1000 tons. Combine two or more pads to achieve higher performance; side by side or together in packs. The quarry hydraulic rock splitter consists of splitting cylinders and a power unit. Cylinders are powered by the high pressure power unit. Fuel tank piston and wedges are the main component of the cylinder. It needs a pre-drill hole of required depth down on the material for movement of the middle wedge. There is a valve on the top of cylinder to control piston work, when the power unit give pressure make the piston work, piston will pressure middle wedge move into bottom, and at the same time, middle wedge will push counter wedges move to sides, a huge horizontal splitting force is produced against to the hole wall, when the tension increases beyond the tensile strength of the material, a split will occur.

More Hide
  • G15 Air Rock Picks Pneumatic Hammer
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydraulic Jacks

    FOB Price:$60-100

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    It's widely used in coal mining, soft rock, digging pits for post brackets, digging slots, breaking concrete, frozen earth in construction and installation engineering or constructing works in casting industries.
    G7 G10 G15 G20
    Weight 7.2 kg 10 kg 15 kg 20 kg
    Length 456 mm 570 mm 580 mm 485 mm
    Cylinder Diameter 35 mm 38 mm 42 mm 40 mm
    Stroke 120 mm 155 mm 155 mm 165 mm
    Working Pressure 0.4~0.5 MPa 0.5~0.63 MPa 0.5~0.63 MPa 0.63 MPa
    Impact Energy 30 J 43 J 55 J 60 J
    Impact Frequency 21.6 HZ 16 HZ 16 HZ 16 HZ
    Air Consumption 1 m3/min 22 L/s 26 L/s 23 L/s
    Air Pipe Diameter 19 mm 16 mm 16 mm 16 mm
  • Stone Quarry Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    FOB Price:$200-600

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Onyx, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Suitable for pushing over the quarry stone after the cut is made by the diamond wire;
    Extremely slim makes it easy to be put into the cut made by diamond wire;
    Reusable for cost savings
  • Hydraulic Stone and Rock Splitter Splitstone S100 for Quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Basalt, Quartzite

    Machinery Function Features:

    SplitStone is hydraulic stone and rock splitter for block and dimension quarry
    The multi unit is typically mounted to tractor or excavator boom or to crane, where the zoom type hydraulic boom is recommended for the longest reach. Each unit has the client specified number of hydraulic wedges. At granite industry for primary splitting up to 20, secondary splitting typically around 12 and like at limestone applications 8.
    Also at the granite quarries the unit is typically equipped in the middle one or two “Opening Wedges”, which after the initial split will be dropped deeper in to cracked hole and from there used to separate the rock totally loose. Every wedge cylinder is mounted to tool balancer. This allows effortless installation of the wedges in to the holes and when the split is done, the loosened cylinder will rise automatically. Hydraulic recommendation is up to 250 bar (3600 psi) and the unit is either radio or remote cable controlled. The cross bar can be equipped with 360 deg. hydraulic rotator to add convenience. S 100 is patented and meets European CE- safety requirements.
    Tecnical details:
    Cylinder diameter 100 mm
    Wedge diameter 29 mm
    Bore size 30 - 32 mm
    Minimum drilling depth 700 mm
    Wedge length 400 mm
    Total length with wedges 1125 mm
    Weight of single wedge 30 kg
    Total weight ~950 kg
    Maximum required
    hydraulic pressure 250 bar
    Flow requirement 50 - 60 l/min
  • Quarry Hydro Bags - expanding steel cushions
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Hydro Bags are expanding steel cushions whose technological brilliance lies in their basic ability to move slabs or blocks of up to 1000 tons or more without the need to prepare slots to house the jacks.
    Hydro Bags have a thickness of just 2mm and can easily be slipped into the diamond wire saw cut.
    They consists of two sheets of high tensile steel welded together using the latest laser techniques.
    Water is hydraulically pumped in at a pressure of 30-40 bar expanding them up to 25-30 cm resulting in a thrust force of up to 1000 tons.
    By coupling two or more cushions side by side or combined together in packs it is possible to obtain greater displacement.
    It must be pointed out that our Hydro Bags only use running water as an expansion fluid and not oil as with other hydraulic systems. It is for this reason that Hydro Bags are classified as environmentally friendly.
    NB! Hydro Bags don’t require any maintenance for the simple reason that they are only used once.
    To summarise, Hydro Bags are a simple, versatile and economical tool that have revolutionised the moving of quarry slabs.
    All this means savings from the following:
    Elimination of the time necessary for the preparation of the slots for jacks
    The blocks of stone are obtained with their sections intact
    Total elimination of explosives which can potentially damage the product
    Partial or total elimination of hydraulic jacks
    Less noise and dust caused by the presence of pneumatic hammers
    Respect for the local environment
    Increased safety for the operators
    Limited maintenance
  • Quarrying Equipment
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Sandstone, Travertine

  • Hydraulic Rock Splitter
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Working on the wedge principle the Hydraulic splitter is the most powerful hand operated tool where splitting force of 350 Ton overcomes any amount of binding strength of rock or concrete cracking it in just seconds.
    Demolition by Splitter is the only solution where blasting is prohibited. Controlled cracking, noiseless - environ friendly operation, user friendly operating techniques, portability, speedy demolition etc. turns hydraulic splitting as an economical substitute in the field of excavations & demolitions.
    The Splitter is inserted in a pre-drilled hole of diameter 48-mm & depth 18 inch. The Hydraulic pressure of 450 to 500 bar (45 MPA) forces a center wedge between the two counter wedges pressing them apart with splitting force of 350 Ton. The force is further transferred to the walls of the hole in the rock and cracks the material in just seconds.
  • Rock Splitter
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Sandstone

    Machinery Function Features:

    CRS Rock Splitter is the latest technology for Rock Excavation / Concrete Breaking in India. It is designed to demolish the rock & concrete economically and environment friendly means without blasting, dust, noise, vibration.

    By Traditional Demolition, 1) Blasting can produce huge quantity of demolition but incurs the safety problem. 2) Hydraulic Breaker can be safe but would sacrifice the production volume while causing environmental problems, - noise, dust, vibration. CRS Rock Splitter can give the answers to those questions, high performance but safe. The all-proof operation, simple structure and low maintenance cost secures its superiority among all other demolition equipment.

    It is applicable to most of rock and concrete demolition and its principle of operation ensures low maintenance and long life. It is used for Building Foundation, Tunneling, City Rock Demolition, Underwater Rock Demolition, Concrete Demolition, Core Drill Demolition and Quarry.
  • Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    FOB Price:

    Warranty: 12 Months

    Usage: Granite, Marble

    Machinery Function Features:

    Single Air Bag
    This machine is used in marble and granite quarry. It can push block upto 4” to 18”. But it depends on block's position. It's been used after all side wire saw machine cut. It can work fast, it's a repairable and work's for a long time.
  • Quarry Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    FOB Price:$180-800

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Owe to its high-efficiency, reusable, economical, and capable to separate and even overturn blocks easily, tidy and not damaged, our air pushing bags are displacing equipment like hydraulic jack and hydro bags in quarries of marble, granite, limestone and so on, no matter blocks cutting by wire saw, blade saw, chain saw, flame jet or cracking powder. We keep innovating and improving to be a leader of air pushing bags, our unique design without an air hose inside makes it easier to put air pushing airbags into cracks between blocks.
    Through our experiment and cooperation with thousands of quarries around the world, introducing Italian advanced equipment and raw material, especially adopting our new technology and new materials, quality of air pushing bag has a new qualitative leap, thickness is same as less than 8mm, but more strength, more reliable quality and longer designed life-span more than half a year, especially more safety.
  • Special Air Bag For Quarrying- Stone Quarry Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    FOB Price:$200-750

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Onyx, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Suitable for pushing over the quarry stone after the cut is made by the diamond wire;
    Extremely slim makes it easy to be put into the cut made by diamond wire;
    Reusable for cost savings.
  • Quarry Hydro Bag Cushions Quarry Equipment
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Sandstone

    Machinery Function Features:

    Hydrobags are supplied in the standard measures 500×500 – 750×750 – 1000×500 – 1000×1000 – 1500×1500 mm.
    DEFAULT SIZES :
    Model Sizes
    C500 50X50 cm
    C750 75X75 cm
    C1000 100X100 cm
    C1500 150X150 cm
    C500x1000 50×100 cm
    Centralina idraulica per Hydrobag, fornita completa di filtro acqua, manometro, tubi e innesti rapidi. La centralina può alimentare contemporaneamente 3 cuscini.
    Hydraulic unit for hydrobag, is supplied complete with water filter, pressure gauge hoses and quick connectors; the control unit can drive simultaneously 3 pillows.
    Quick connectors for hydraulic unit.
  • SOOSAN SB81 Hydraulic Breaker for 18-26 ton Excavator
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydraulic Jacks

    $1000-10000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Our hydraulic breaker could fit to any brand excavator from 0.5-70 ton
    Chisel from 35-210 mm
    Unit price with spare parts as below:
    1: With plywood box package
    2: With standard spare parts
    2 chisels
    2 oil piping
    1 N2 gas bottle
    1 tool box
    1 N2 pressure gauge
    Deliver time: 7-15 days after down payment
    Deliver method: By sea or by air based on your request
  • Pompa Hydro Bag
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Hydrobag is a pump for filling cushion with water, for borrow material excavation.

    Hydro bag is composed by:

    - pressure power unit Hydro bag with electric engine 5,5 Hp

    - supported wheelbarrow and water reservoir

    - safety and distribution valves

    - aspiration and pressure pipes and aspiration filter

    - Series of fast couplings - thrust up to 1000 tonnes, dilatation 25-30cm

    - supply plug and engine - saver interrupter.

    Cushions are available: CM 50x50, CM 80x80, CM 50X100, CM 100x100, CM 150x150.
  • HP120 - Machine Spaccaroccia
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Sandstone, Travertine

    Machinery Function Features:

    HP120 - Machine spaccaroccia

    E 'designed to be applied on a telescopic handlers with a maximum load arm of at least 1250 kg. It is equipped with adequate number of hydraulic wedges (12 to 20 elements) for the cutting of the rock drilled linearly.

    The working cycle is performed by a single operator using procedure similar to that traditionally performed with punciotti manual, but with time running very low and lengths of cut maggiori.La flag portacunei machine is positioned near the line of drilling el ' operator can easily insert the wedges into the holes, which are put under pressure by remote control or remote control.

    Compared to the manual process, the spaccaroccia HP 120 allows the operator to do other than potentially very dangerous tool and cut the stones away from the safe. The machine can contribute, among other things, the reduction of 'explosive in quarrying.
  • Quarry Hydro Bag with Motor
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Marble, Limestone, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    THE HYDRO (WATER) BAG IS MANUFACTIRED FROM THE FINEST HIGH QUALITY TENSILE STEEL , HEREBY QUARANTEEING FLAWLESS PERFORMANCE .THE BAG IS INSERTED IN THE CRACK IN THE BLOCK AND IT SEPARATED THE BLOCK AS S0ON AS WATER IS INSERTED IN THE BAG WITH THE HELP OF THE WATER PUMP.
    DIMENSION
    1 * 1 MTR
    1 * 0.5 MTR
  • Quarry Block Pusher Air Bags / Hydro Bag for Quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Marble, Limestone, Sandstone, Travertine

    Machinery Function Features:

    Air Bag or Block Pusher is used to split granite or marble blocks from mountain .
  • Hydro Bag
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble

    Machinery Function Features:

    Hydro Bag
    The Hydro (Water) bag is manufactured from the finest quality high tensile steel. Hereby guaranteeing flawless performance. The bag is inserted in the crack in the block and it separates the block.

    Machine is equipped with 2 HP.AC. motor.
    Hydro bag is operated with Water pump.
    It is use and throw type bag. It's usable for one time.
  • Titano Oleodynamic Quarry Bench Pushing Unit
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydraulic Jacks

    Warranty: 12 Months

    Usage: Marble, Limestone, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    A pair of hydraulic cylinders for bench tipping. The unit composed of:Oleodynamic device equipped with a two stages pump for use 700 atm. That can be powered either by tree phase 3 HP electric motor 220/380 Volts with reversing (Tiatano/E Model) or by compustion engine 5 HP and automatic adjuster (Titano/SC model) or by pneumatic motor 3.5 HP(Titani/PN). The unit is composed of: two jacks manufactured in specially treated stell whit chromed cylinder and complete with quick couplings, safety valves and limit switch; each jack ton pushing capacity.

  • Hydraulic Jack
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydraulic Jacks

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Sandstone

    Machinery Function Features:

    This machine is used in marble and granite quarry. It is used to push the stone. Hard chrome is applied to on piston. Its very hardened material. H6. 486 hydraulic cylinder hardened and grinding. Hydraulic pump 3 way piston polyhydron made. Oil seal of bronze Teflon is used so that it can be usable for long life.
    Description
    Machine is equipped with 2 HP.AC. Motor
    Hydraulic jack pushing capacity is 6 Inches & Whatever is your need.
    Hydraulic jack and power pack capacity 300 tons.
  • Hydro Bag for Quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Sandstone, Travertine

    Machinery Function Features:

    Hydro-bag
    This has happened in the marble and stone quarrying industry , specifically for stripping blocks from the mountain .
    HYDRO-BAG has completely upset bench excavation in quarries .
    The revolutionary aspect of the HYDRO-BAG equipment lies basically in the possibility of stripping blocks up to 1000 tons or more , without the need to prepare slots to house the jacks since the HYDRO-BAG has an original thickness of just 2 mm ( 0.08) and can be easily slipped into the wire saw cut .

    Crack-rock
    Crack-rock is a highly expansive mortar to demolish and cut rocks and concretes . crack-rock swell when poured into a
    Hole and develops a pressure higher than 7500 t/m2 on the hole walls , thereby breaking them open . crack-rock is environmentally friendly because it releases on toxic fumes or harmful substances of any kind .
  • Pneumatic Tipping Cushion Quarry Air Pushing Bag
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    Warranty: 12 Months

    Usage: Marble, Limestone, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Splitting cushions in polyester material spread with PVC and FH sealed. Instertable in size of 9mm with adequate protective sheet. Maximum inflated pressure 3 Atm. Max. split to a limit of 45 cm.Complete with an inflatable centre suitable for the use of maximum of 3 cushions simultaneously.
  • HYDROSPLIT HS-230 Hydraulic rock splitting cylinders
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Onyx, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Special double acting hydraulic cylinder that drives a wedge, mounted upon the shaft, which, when inserted between a pair of lateral feathers, creats a considerable pressure agains the sides of the hole into which the conical assembly has been placed, thus achieving the breakage of the material.

  • Hydro Bag
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Quartzite, Sandstone

    Machinery Function Features:

    This has happened in the marble and stone quarrying industry , specifically for stripping blocks from the mountain .
    HYDRO-BAG has completely upset bench excavation in quarries .
    The revolutionary aspect of the HYDRO-BAG equipment lies basically in the possibility of stripping blocks up to 1000 tons or more , without the need to prepare slots to house the jacks since the HYDRO-BAG has an original thickness of just 2 mm ( 0.08 ) and can be easily slipped into the wire saw cut .
  • HYDRO BAG Tipping cushions using high pressure water
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Marble, Limestone, Slate, Onyx, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    HYDRO BAG Tipping cushions using high pressure water

    HIDRO-BAG offer the following advantageous:

    features:

    -doesnt ruin the block

    -weight a mere 8 kg

    - it is only 2mm thick

    -can be iserted in the diamond r helicoidal saw cut

    -has a thrust development of 300 tons

    -works with water, at 30 atm only.

    -it is provided whit rapid coupling

    -does not required maintenance

    -can be thrown after use
  • Stone block polymer quarrying pushing air bag
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $100-500

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Bestlink Factory Price Quarry Block Air Bag Pushing for Marble Granite
    Quarry block pushing air bag is used to separate the marble, granite, stones (rock mass) block from the basic rock achieving a maximum opening of 45-120cm at the top. The air bag can separate the block (rock mass) which is having all side wire saw cut faces. The standard configuration set contains two air bags, with one set of air hose & air control panel.
    Our air pushing bag is manufactured with high-tech materials and processed by special techniques, no frequent problem happened in split and damage.
    Owe to its high-efficiency, reusable, economical and capable to separate, even overturn the blocks easily, tidily and without damage, BESTLINK pushing air bag is displacing the traditional equipments like hydraulic jack and steel hydro-bag in quarries of marble, granite, limestone and so on, no matter blocks cutting by wire saw, blade saw or chain saw.
    We always keep innovating and improving to be the leader of pushing air bag products. Our unique design and advanced tachnique make it easier to put the air bags into the gap after diamond wire saw cutting.
    Through our experiment and co-operation with hundreds of quarries all over the world, bringing in Italian advanced production euiqpments and super level raw material, especially adopting our new technology, Sansung made pushing air bag has got big progress on the quality. With same thickness less than 7mm, but more powerful and safe in long term use.
  • Stone Pushing Tool Steel Hydro-bag After Wire Saw
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    $13-40

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Sandstone

    Machinery Function Features:

    The steel cushion Hydro-Bag is widely used in the marble and stone quarrying industry,specially for stripping blocks from the mountain. The revolutionary aspect of the HYDRO-BAG equipment lies basically in the possibility of stripping blocks up to 1000 tons or more, without the need to prepare slots to house the jacks since the HYDRO-BAG has an original thickness of just 2 mm (0.08") and can be easily slipped into the wire saw cut.
    A complete HYDRO-BAG equipment consists of:
    1. Electric or pneumatic pump unit to create the pressure for the cushions;
    2. Safety valves and distribution valves;
    3. Pipes, cocks and inlet filters;
    4. Quick couplings;
    5. A series of HYDRO-BAG cushions.
  • OVERTURNING BLOCK EQUIPMENT Mod. KW11- Quarry Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    TECHNICAL SPECIFICATION
    Model KW 11
    Power of main electric motor 1.1 Kw / 1.5 Hp
    Max pressure 40 bar
    Metal bag shim 2 / 2.5 mm
    Std bag dimensions 100 x 100cm
    Push force up to 1000 ton
    Weight of the machine 29 kg.
    Walls overturning system composed of a high pressure electric pump, wich swells some metal "pillows" in order to move big blocks and walls.
  • Eurovinil Air Cushions For Overturning Stone Blocks- Quarry Air Pushing Bags
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Onyx, Sandstone

    Machinery Function Features:

    Eurovinil air cushions for overturning stone blocks are reusable hundreds of times, supplied in standard size 1500×1000 – 2000×1600 – 2800×1600 mm.
    DEFAULT SIZES :
    Sizes
    50X50 cm
    75X75 cm
    100X100 cm
    150X150 cm
    50×100 cm
  •  Pump For Hydrobag Quarry Equipment
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Quartzite, Sandstone

    Machinery Function Features:

    Pump for hydrobag.

    Datasheet:
    Pressure 30 bar
    Max pressure (50 bar Max)
    Scope litres / min 11
    Time filling cushion 100×100 – H = 20 cm. 19 minutes
    Power installed 1.1 kW (1.5 hp)
  • 70ton Four Blades Hydraulic Sawn Stone Splitting Machine Guillotine
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    $14000-16000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Hydraulic splitting machine
    It suitable for splitting all types of natural and artifical stones,used for the production of large and small materials for mosaic and stone flooring.and characterized by high reliability and easy handling,every splitting machine can be integrated in a production line,especially designed according to your needs.
    Using our splitting machines you could produce a wide range of products like: Cobble stones, Paving stones, Tiles for paving and cladding, Wall stones and Kerb stones, etc. Our machines are known also as splitters, hydraulic splitting machines, stone splitter or stone cutter (for rustic products).
    The hydraulic system of our machines mainly uses the hydraulic components of German Bosch Rexroth with stable performance, no oil leakage, low noise and long service life and so on.
    Electrical system of our machines is safe, reliable, convenient and flexible and the components are from the brands ofSchneider and Omron.
    The machines can be operated automatically or manually and move continuously or single-step. Equipped with a separate control cabinet, the electric control part can be operated by a total station and a button box. The start-up and operation is very convenient.
    The character of the machine is of intelligent gear cutting head, can adjust itself according to the condition of the stone face, and then, generate hydraulic power to split the stone down in a spot. Therefore it is of high speed, good quality, low consumption and so on, which can improve products quality and production efficiency in a high degree.
  • Hot Sale Pushing Air Bag for Marble and Granite Block Cutting
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $180-1000

    Warranty: 12 Months

    Usage: Granite, Marble

    Machinery Function Features:

    Hot Sale Pushing Air Bag for Marble and Granite Block Cutting
    1.Air pushing bag
    2.put into the aperture easily
    3.Strong pushing power
    4.Max capacity:200 tons
    5.can be used for many times
    Pushing air bag is often used in stone quarrying after cutting by wire saw. High-materials
    and special processing technique.
    The characters of our air bags:
    1. Less than 7mm thickness
    2. Strong pushing power
    3. High-tech materials and special processing techniques
    4. No frequent problem in split and damage
    5. Can be reused
    It's max pushing capacity could reach to 200 tons.
    IT CAN BE USED FOR MANY TIMES; SOME OF OUR CUSTOMERS JUST USE ONE BAG
    ONE YEAR!
    Technical Data
    Model Specification Theoretical pushing capacity weight(kg)
    BL1010 1.0m×1.0m 50tons 4.5kg
    BL1015 1.0m×1.5m 75tons 6.8kg
    BL1020 1.0m×2.0m 100tons 9.0kg
    BL1515 1.5m×1.5m 115tons 10.2kg
    BL2015 2.0m×1.5m 150tons 13.5kg
    BL2020 2.0m×2.0m 200tons 18.0kg
    BL3030 3.0m×3.0m 450tons 40.5kg
    Control platfrom for above air bag air pressue 0-6bar,3 outlet 30.0kg
  • Safe Easy Operation Stone Pushing Tool Air Bags for Quarrying
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $180-1000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Safe Easy Operation Stone Pushing Tool Air Bags for Quarrying
    Application:
    Bestlink Polymer blocks air pushing bag is used to separate the marble, granite, stones(rock mass) block from the basic rock achieving a maximum opening of 45cm at the top. The air bag can separate the block (rock mass) which is having all side wire saw cut faces. It performs primely and is suitable for blocks splitting after wire saw cutting in quarry.
    And the small air bags also can be used for stone factory to seperate stone slabs after multi-blade saw cutting.
  • Rock and Concrete Block Hydraulic Splitter for Quarry and Construction
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    $250-5000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Rock and Concrete Block Hydraulic Splitter for Quarry and Construction
    Instruction
    1. The hydraulic rock and concrete splitter is a kind of hand-hold splitting and demolition too
    2. It can controllably split rock or concrete
    3. Especially suit for cabined area where large machine can not work
    4. Wodely use in the place where need non-explosive and blast forbidden

    Description:
    1. Hydraulic rock splitter is maninly composed of power pump pack and hydraulic cylinder.
    Mainly applicable to the secondary breaking.
    2. First drill hole in stone, then insert hydraulic cylinders which is contain wedge and feathers,
    Start engine to provide hydraulic pressure.
    3. Repeat the process until the whole structure is fractured into smaller sections and ready for
    Removal.
    Advantages:
    1. Enormous splitting force up to 500 tons & vibration free
    2. Dust free and near silent operation & Light weight and Easy handling
    3. Different sizes of counter wedge and center wedge can use on the same splitter
    Application:
    1. Split all kinds of natural stones, rock, granite, marble mining & quarrying
    2. Remove redundant reinforced concrete structures, concrete machine beds and plinths etc.
    3. Underwater demolition & Demolition in a restricted space
    4. Controlled demolition of pillars, concrete and walls where heavy equipment is impractical
  • Electric/Diesel Hydraulic Rock Stone Concrete Splitting Machine
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    $250-5000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Quartzite, Sandstone

    Machinery Function Features:

    Electric/Diesel Hydraulic Rock Stone Concrete Splitting Machine
    It is our newly developed products for quarrying and civil construction, which is mainly applicable to the secondary breaking of large boulders, squaring breaking of large boulders ,squaring blocks. Driven Mortor: Electric / Diesel / Gasoline / Pneumatic.
    BS36/38/40 uses Iron Cylinders, BS42/45 have both Iron and Aluminium Alloy cylinders. Aluminium Alloy cylinder is ighter and stronger. Besides, we already successfully copied the same cylinder from German Darda, and the model no. is C12 (N), it is with the same shape,same parts and same performance as the original one.
    Features:
    1)Enormous splitting force up to 410 tons
    2)Dust free and near silent operation
    3)Vibration free
    4)Light weight
    5)Precision work
    6)Always controllable
    7)For use in close quarters and hard to access places.
    8)Easy handling
  • Bestlink Factory Directly Custom Size Quarry Blocks Pushing Air Bag for Mining
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $142-850

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Factory directly custom size quarry blocks pushing air bag for mining
    Advantages:
    1.Less than 7mm thickness
    2.Strong pushing power
    3.High-tech materials and special processing techniques
    4.No frequent problem in split and damage
    5.Can be reused
    6.After inflation by air compressor, the pushing power of the air bags can reach 50 tons to 450 tons according to different sizes of the pushing bags.
    Polymer blocks pushing air bag is used to separate the marble, granite, stones(rock mass) block from the basic rock achieving a maximum opening of 45cm at the top.The air bag can separate the block (rock mass) which is having all side wire saw cut faces.
  • Red polymer marble block push air bag for various quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $145-850

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    red polymer marble block push air bag for various quarry
    1.Air pushing bag
    2.put into the aperture easily
    3.Strong pushing power
    4.Max capacity:200 tons
    5.can be used for many times
    Pushing air bag is often used in stone quarrying after cutting by wire saw. High-materials
    and special processing technique.
    The characters of our air bags:
    1. Less than 7mm thickness
    2. Strong pushing power
    3. High-tech materials and special processing techniques
    4. No frequent problem in split and damage
    5. Can be reused
    It's max pushing capacity could reach to 200 tons.
    IT CAN BE USED FOR MANY TIMES; SOME OF OUR CUSTOMERS JUST USE ONE BAG
    ONE YEAR!
    Technical Data
    Model Specification Theoretical pushing capacity weight(kg)
    BL1010 1.0m×1.0m 50tons 4.5kg
    BL1015 1.0m×1.5m 75tons 6.8kg
    BL1020 1.0m×2.0m 100tons 9.0kg
    BL1515 1.5m×1.5m 115tons 10.2kg
    BL2015 2.0m×1.5m 150tons 13.5kg
    BL2020 2.0m×2.0m 200tons 18.0kg
    BL3030 3.0m×3.0m 450tons 40.5kg
    Control platfrom for above air bag air pressue 0-6bar,3 outlet 30.0kg
  • Block pushing air bag  1.0m*1.5m for sandstone, limestone quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Air Pushing Bags

    $140-850

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    Manufacturers of Mining Equipment China Gold Quarry Stone Machine Block Pushing Air Bag
    Quarry block pushing air bag is used to separate the marble, granite, stones (rock mass) block from the basic rock achieving a maximum opening of 45-120cm at the top. The air bag can separate the block (rock mass) which is having all side wire saw cut faces. The standard configuration set contains two air bags, with one set of air hose & air control panel.
    Our air pushing bag is manufactured with high-tech materials and processed by special techniques, no frequent problem happened in split and damage.
    Owe to its high-efficiency, reusable, economical and capable to separate, even overturn the blocks easily, tidily and without damage, Bestlink pushing air bag is displacing the traditional equipments like hydraulic jack and hydro-bag in quarries of marble, granite, limestone and so on, no matter blocks cutting by wire saw, blade saw or chain saw.
    We always keep innovating and improving to be the leader of pushing air bag products. Our unique design and advanced tachnique make it easier to put the air bags into the gap after diamond wire saw cutting.
    Through our experiment and co-operation with hundreds of quarries all over the world, bringing in Italian advanced production euiqpments and super level raw material, especially adopting our new technology, Bestlink made pushing air bag has got big progress on the quality. With same thickness less than 8mm, but more powerful and safe in long term use.
    Quarry block pushing air bag is used to separate the marble, granite, stones (rock mass) block from the basic rock achieving a maximum opening of 45-120cm at the top. The air bag can separate the block (rock mass) which is having all side wire saw cut faces. The standard configuration set contains two air bags, with one set of air hose & air control panel.
    Our air pushing bag is manufactured with high-tech materials and processed by special techniques, no frequent problem happened in split and damage.
    Owe to its high-efficiency, reusable, economical and capable to separate, even overturn the blocks easily, tidily and without damage, Bestlink pushing air bag is displacing the traditional equipments like hydraulic jack and hydro-bag in quarries of marble, granite, limestone and so on, no matter blocks cutting by wire saw, blade saw or chain saw.
    We always keep innovating and improving to be the leader of pushing air bag products. Our unique design and advanced tachnique make it easier to put the air bags into the gap after diamond wire saw cutting.
    Through our experiment and co-operation with hundreds of quarries all over the world, bringing in Italian advanced production euiqpments and super level raw material, especially adopting our new technology, Bestlink made pushing air bag has got big progress on the quality. With same thickness less than 8mm, but more powerful and safe in long term use.
  • Hydraulic Rock Splitter - Stone Splitting Machine
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    $5000-55000

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine

    Machinery Function Features:

    Our Hydraulic stone splitting machine is suitable for splitting all types of natural and artificial stones, cube stone/curb stone/wall stone/blockstone/tiles/pavingstone/countertops/vanity tops.
    It has floating teeth up and down,we also called it individual chisels which can make Hydraulic stone splitting machine tch the natural surface of the stones perfectly.
    Every splitting machine can be integrated in a production line, especially designed according to your needs.
    The main characters of our machines are:
    1. The electrical control cabinet adopt the French Schneider, with internal layout reasonable and neat, and
    through the senor switch to facilitate rapid signal to make the movements of the machine consecutive and accurate.
    2.The hydraulic system adopts from German Bosch Rexroth, providing sustainable,stable and sufficient
    power to the machine.
    3.With intelligent gear cutting head, itcould adjust itself according to the smooth condition of the stone surface.
    4. We can design a wonderful stone cutting line from blocks to paving stone, wall stone, mosaic, cobble stone, etc, upon the demand of customers
  • DARDA Hydraulic Rock and Concrete Splitters
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterHydraulic Rock Splitter

    $1800-5800

    Warranty: 12 Months

    Usage: Granite, Marble, Limestone, Slate, Basalt, Quartzite, Sandstone

    Machinery Function Features:

    DARDA hydraulic Rock and Concrete Splitters
    The hydraulic rock and concrete splitter is a kind of hand-hold splitting and demolition tool. It can controllably split rock or concrete. Especially suit for cabined area where large machine can not work.Such as hydraulic breaker and place where is strictly limited of noise, dust, flying debris, shake, exhaust gas, also widely use in the place where need non-explosive and blast forbidden.
    Hydraulic Splitter models and parameters: BS36/38/40 BS42/4546/48
    Driven Mortor: Electric / Diesel / Gasoline / Pneumatic.
    BS36/38/40 uses Iron Cylinders,
    BS42/45 have both Iron and Aluminium Alloy cylinders.
    Aluminium Alloy cylinder: Lighter and stronger! !
    Besides, we already successfully copied the same cylinder from German Darda, and the Model No. Is C12 (N), ithave the exact same shape, same parts and same performance as the original one.
  • Marble Sandstone Block Pushing Steel Cushion Hydro Bag for Quarry
    favorites
    Add To Compare

    Type: Quarry MachinesQuarry Hydro-Bags, Rock SplitterQuarry Hydro-Bags

    $40-

    Warranty: 12 Months

    Usage: Marble, Limestone, Sandstone

    Machinery Function Features:

    The steel cushion Hydro-Bag is widely used in the marble and stone quarrying industry,specially for stripping blocks from the mountain. The revolutionary aspect of the HYDRO-BAG equipment lies basically in the possibility of stripping blocks up to 1000 tons or more, without the need to prepare slots to house the jacks since the HYDRO-BAG has an original thickness of just 2 mm (0.08") and can be easily slipped into the wire saw cut.
    A complete HYDRO-BAG equipment consists of:
    1. Electric or pneumatic pump unit to create the pressure for the cushions;
    2. Safety valves and distribution valves;
    3. Pipes, cocks and inlet filters;
    4. Quick couplings;
    5. A series of HYDRO-BAG cushions.

Have a Question? Ask our expert

Questions & Answers on Quarry Hydro-Bags, Rock Splitter

What is Quarry Hydro-Bags maximum thrust force?

Posted by Visitor

reply icon Reply to this question 1Reply

The hydro bags expand under the pressure of water pumped at 30-40 bar, permitting a maximum dilatation of 25-30 cm (approx. 1’) and a thrust force up to 1000 tons. Couple two or more cushions to obtain higher performances; side by side or combined together in packs.

Answered by StoneContact

Like

What is the average size of hydro bags?

Posted by Visitor

reply icon Reply to this question 1Reply

Its average dimensions vary from 500*500 mm to 2300*2300 mm.

Answered by StoneContact

Like

What are the average weights of Quarry Hydro-Bags?

Posted by Visitor

reply icon Reply to this question 1Reply

Quarry Hydro-Bags average weight vary from 3 kg to 15 kg.

Answered by StoneContact

Like

How do quarry rock splitters work?

Posted by Visitor

reply icon Reply to this question 1Reply

The working principle of quarry rock splitter is based on two counter wedges inserted in a pre-drilled hole. A hydraulic cylinder pushes out a centre wedge between the counter wedges to spread them apart and the rock is forced to crack.

Answered by StoneContact

Like

Clear All
Compare (0/4)
StoneContact
Tips

Tell Suppliers what you want to buy
