Automatic Litchi Surface Processing Machine
FOB Price:
Type:
Stone Factory MachinesStone Surface Processing Machines Bush Hammering Machine
Usage:
Granite, Marble
After-Sale
Warranty:6 Months
Supplier
Eatablished :Mar 24,2003
Main Product:
Multiple Blades Brige Stone Cutting Machine, 3D CNC Stone Cutting Machiine, Infra Red Stone Cutting Machine, Stone Coping Machine, Multiple Autoo Slab Polishing Machine|
Contact supplier
You may also like
Machinery Function Features
This machine is the initiative products in China. It adopts three-beam structure, and the grinding head can realize the movement trajectory through the variable frequency speed regulation. By the adjustable conveyor belt speed to realize continuous processing, it will finish the slab processing one times with the entire automatic control . As a result of multi-curve and multi-combination grinding wheel processing, It will reach high produce efficiency and very ideal processing effect. Production output is 50-70 square meters per hour. It improve the labor efficiency and reduce production costs greatly. It is the only Litchi surface processing machine to process one-cm thickness slab.
Technical Data
Parameters |
Unit |
DTALZM-1000-6 |
Production output |
m2/h |
40-50 |
Reducer motor power |
kW |
4.5 |
Reducer motor for conveyor |
kW |
1.5 |
Voltage |
V |
380 |
Machine overall length |
mm |
4600 |
Machine overall width |
mm |
2400 |
Approx. Weight |
Kg |
4000 |
Max. processing thickness |
mm |
80 |
Max. processing width |
mm |
900 |
Machine overall height |
mm |
1900 |
The size load in truck (L*W*H) |
mm |
4600*2100*1900 |
Main motor power |
kW |
13.2 |
Loading frame size (L*W*H) |
mm |
2500*1400*800 |
Min. processing thickness |
mm |
20 |
