Mobile Drilling Machine Y325- Quarry Drilling Machine
FOB Price:
Type:
Stone Quarry MachinesQuarry Drilling MachineHorizontal Pneumatic Mobile Rock Drill
Usage:
Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Remote troubleshooting
Supplier
Eatablished :Dec 30,2000
Main Product:
Chainsaw Machine, Drilling Machine, Diamond Wire Cutting Machine, Block Sizing Machine, Horizontal Block Sizin Machine, Diamond Wire With Bridge|
Contact supplier
You may also like
Machinery Function Features
Description:
Diesel Engine: 18 Hp ( Antor)
Electrical Motor: 75kw
Hydraulic Pump: Piston Type
Motion: 3 wheel drive
Stem Length: 2 meters.
Air Prussure: 10 bar and above ( special manufacturing)
Drilling Speed: 0,25-0,5 m/min
Drilling Rotation: Horizantal and Vertical
Weight: 4400 kg
Width : 1950 mm
Length: 6000 mm
Heigth: 1350 mm
Notes: You can move in the marble quarries easily wherever you want and you can drill.
It can move until 30° ramps angle.
Diesel Engine: 18 Hp ( Antor)
Electrical Motor: 75kw
Hydraulic Pump: Piston Type
Motion: 3 wheel drive
Stem Length: 2 meters.
Air Prussure: 10 bar and above ( special manufacturing)
Drilling Speed: 0,25-0,5 m/min
Drilling Rotation: Horizantal and Vertical
Weight: 4400 kg
Width : 1950 mm
Length: 6000 mm
Heigth: 1350 mm
Notes: You can move in the marble quarries easily wherever you want and you can drill.
It can move until 30° ramps angle.
Technical Data
Parameters |
Unit |
Y325 |
Diesel Engine |
HP |
18 Hp ( Antor) |
Overall Length |
mm |
6000 |
Starting Drill Stell |
m |
2 |
Drilling speed |
m/min |
0,25-0,5 |
Air pressure |
bar |
up to 10 |
Overall Width |
mm |
1950 |
Overall Height |
mm |
1350 |
Electrical Motor |
kW |
75 |
Total Weight |
Kg |
4400 |
Hole Diameter |
mm |
90-100 |
