Slabs Loading Trolley With Suction Cups- Automatic Loader, Unloader For Slabs

– Automatic loading car with suction cups for feeding granite slabs in a production line.
– Movable frame, composed of a motorized carriage and a tilting table with a motorized roller frame and a set of vacuum equipment to activate the suction cups for receiving material, to collect the boards stacked in a semi-vertical position and deposit them on the rollers from the feeding table to the production unit. For feeding the boards stacked in a vertical position, it also has joints in the suction cups, activated by hydraulic cylinders to approach the boards in a vertical position and fold them down to deposit them on the roller table in the
loading position.
– Movable trolley on rolling tracks anchored to the ground to approach the material stowage units, with wheels driven by an electric gear motor.
– The programming and the sequence of work is done by selecting from the control panel. Smooth and precise movements thanks to the installation of frequency converters in the translation movement.
