MAS Multipurpose Machine-Cutting, Edge Profiling, Polishing and Chamfering Machine
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesEdge Profiling, Polishing Machine
Usage:
Granite, Marble, Limestone, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Remote troubleshooting
Supplier
Eatablished :Dec 31,1949
Main Product:
Floor Grinder, Compact Bridge Saw With Turning Head, Mitre Saw Machines, Compact Bridge Saw With Mobile Bridge, Tile Cutting Machines, Bridge Saw With Turning Table For Marble|
Contact supplier
Machinery Function Features
MAS is a fully equipped multipurpose machine which can be used for cutting, edge profiling, polishing and chamfering straight edges by simply changing the head tool.
ADVANTAGES
MAS is a multipurpose saw for cutting stone slabs as well as profiling, polishing and chamfering straight edges:
Multipurpose machine fully customizable according to customer requirements;
The atmost precision is guaranteed by a compressed, rectified and chromed “active beam”;
Motorized head travel with variable speed on X and Z-axis in both forward and backward directions;
2-speed main motor to optimize machining of all types of stone: for marble (7.5kW=10HP) and for granite (5.5kW=7.5HP).
ADVANTAGES
MAS is a multipurpose saw for cutting stone slabs as well as profiling, polishing and chamfering straight edges:
Multipurpose machine fully customizable according to customer requirements;
The atmost precision is guaranteed by a compressed, rectified and chromed “active beam”;
Motorized head travel with variable speed on X and Z-axis in both forward and backward directions;
2-speed main motor to optimize machining of all types of stone: for marble (7.5kW=10HP) and for granite (5.5kW=7.5HP).
Technical Data
Parameters |
Unit |
MAS |
Diameter of the drip board saw blade |
mm |
400 (Blade bore size: 50mm) |
Calibrating spindle rotation speed |
r/min |
1400 rpm 50Hz – 1700 rpm 60Hz |
Main motor power |
kw |
5.5/7.5kW - 7.5/10HP (3ph.) |
Bevel tools Diameter dimension |
mm |
Bore size 35mm – lower diameter 60mm |
Z axis travel |
mm |
240 |
Polishing spindle rotation speed |
r/min |
1400 rpm 50Hz – 1700 rpm 60Hz |
Standard voltage-frequency |
V/Hz |
400V-50/60Hz / 230V-60Hz 3ph. |
X axis travel |
mm |
3100 |
