JNIR-400/800 Laser Bridge Cutting Machine (Guide Post)
FOB Price:
Type:
Stone Factory MachinesStone Slab Cutting MachinesCNC Bridge Cutting Machine
Usage:
Granite, Marble, Limestone, Artificial Stone, Basalt, Quartzite
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Remote troubleshooting, Field troubleshooting
Supplier
Eatablished :Dec 28,2000
Main Product:
Stone Balustrade Machine, Stone Ball Machine, Stone Column Machine, Stone Engraving Machine, Stone Cutting Machine, Stone Polishing Machine|
Contact supplier
You may also like
Machinery Function Features
JNIR-400/800 Laser Bridge Cutting Machine (Guide Post)
Features:
1. It is equipped with oil-immersed guide way for crossbeam and edge beam;
2. Hydraulic controlled elevation system;
3. PLC terminal controlling system for convenience of setting parameters through LCD touch screen.
Each slab is cut automatically individually throughout the process, with blade input speed flexibly adjusted
by variable frequency adjustable speed system according to slab characteristics;
4. An infrared ray cutter aligner is installed;
5. Cross Beam: Double built-in groove to make precise cutting;
6. Double hydro-cylinder: blade elevation is more stable.
Features:
1. It is equipped with oil-immersed guide way for crossbeam and edge beam;
2. Hydraulic controlled elevation system;
3. PLC terminal controlling system for convenience of setting parameters through LCD touch screen.
Each slab is cut automatically individually throughout the process, with blade input speed flexibly adjusted
by variable frequency adjustable speed system according to slab characteristics;
4. An infrared ray cutter aligner is installed;
5. Cross Beam: Double built-in groove to make precise cutting;
6. Double hydro-cylinder: blade elevation is more stable.
Technical Data
Parameters |
Unit |
JNIR-400/800 |
Machine height |
mm |
2800 |
Operating voltage/frequency |
V/Hz |
380V/3PH/50Hz |
Worktable turn-over degree |
° |
0-90° |
Machine width |
mm |
5000 |
Max. cutting depth |
mm |
140 |
Approximate weight without table |
Kg |
5300 |
Table tilting angle |
° |
0-85° |
Max.length of the cut slab |
mm |
3200 |
Cooling water requirement(1.5 bar min. pressure) |
m3/h |
5 |
Max.width of the cut slab |
mm |
2000 |
Disc diameter |
mm |
400-800 |
Dimensions of the work table(L×W) |
mm |
3200x2000 |
Machine length |
mm |
6000 |
Installed electrical power |
kw |
15-30 |
Number of vertical cutting spindles |
nr |
1 |
