MAX2-2500 Bridge Combined Block Cutting Machine (Extra Large)
FOB Price:$61200-63200
Type:
Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
WITHIN 30 DAYS AFTER RECEIVING THE DEPOSITS
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Online software upgrade, Remote troubleshooting
You may also like
Machinery Function Features
MAX2-2500 uses PLC system and Human-machine interface, combined with Ultra-high precision rotary encoder to slice, uses inverter to control left-right feeding and adjusts the speed according to the stone material. It uses hydraulic lifting system, and the forward-backward slicing uses high-precision screw nut driving, automatic slicing.The key part adopt imported good-quality spare parts.The block can be placed on the ground directly and economize the worktable and its maintenance costs; The whole machine is featured with high cutting efficiency, high slicing precision, flatness of plate after cutting, high stability, easy-operating, suits for cutting market slab, common slab, big slab and high-value slab.
Technical Data
Parameters |
Unit |
MAX2-2500 |
Machine length(front) |
mm |
10000 |
Crossbeam |
mm |
9500 |
Guide pillar diameter |
mm |
210 |
Sidebeam |
mm |
5000 |
Machine width |
mm |
5700 |
Max. cutting depth |
mm |
1050 |
Forward-backward stroke |
mm |
3200 |
Main motor power |
kw |
110 |
Vertical disc diameter |
mm |
2500 |
Left-right stroke |
mm |
5200 |
Machine height |
mm |
4200 |
Approximate Weight |
Kg |
19500 |
